Kelford Cams Street Performance Camshafts Toyota 2JZ VVTi V202-B

Kelford Cams Street Performance Camshafts for Toyota 2JZGTE VVTi V202-B. 260 / 260 Degrees advertised duration. 9.35mm/9.35mm lift. To suit Toyota 2JZ VVTi. Street performance cams to suit engines with turbo and ECU upgrades. Suits up to 30lb boost and 7500 RPM with Kelford Cams recommended valve spring. Will also drop in on stock spring.

• Brand: Kelford Cams
• Manufacturer Part Number: V202-B
• Valve Clearance:
  Intake: 0.25mm Set COLD at the CAM
  Exhaust: 0.25mm Set COLD at the CAM
• Cam Lift:
  Intake: 9.60mm
  Exhaust: 9.60mm
• Rocker Ratio:
  Intake: 1.00
  Exhaust: 1.00
• Net Valve Lift:
  Intake: 9.35mm
  Exhaust: 9.35mm
• Advertise Duration @ 0.10mm:
  Intake: 260
  Exhaust: 260
• Duration @ 1.00mm Valve Lift:
  Intake: 222
  Exhaust: 222
• Timing @ 1.00mm Valve lift:
  INVO:
  EVO: 50 BBDC
  IVC:
  EVC: 8 BTDC
• Suggested Centre Lines:
  Intake: VARI
  Exhaust: 116
• Valve Lift @ TDC
  Intake:
  Exhaust: 0.26mm
