Kelford Cams

Kelford Cams Street Performance Camshafts Toyota 1JZ VVTi V229-B

Kelford Cams Street Performance Camshafts Toyota 1JZ VVTi V229-B

Regular price $909.00 USD
Regular price Sale price $909.00 USD
Sale Sold out
Shipping calculated at checkout.

Kelford Cams Toyota 1JZ - VVTi Street Performance Camshafts V229-B. 260 / 260 Degrees advertised duration. 9.35mm / 9.35mm lift. Street performance cams to suit turbo and ECU upgrade. Suits up to 30 lb boost and 7500 RPM with our recommended valve spring. Will suit stock valve spring with stock redline.

  • Brand: Kelford Cams
  • Manufacturer Part Number: V229-B
  • Valve Clearance:
    Intake: 0.25mm Set COLD at the CAM
    Exhaust: 0.25mm Set COLD at the CAM
  • Cam Lift:
    Intake: 9.60mm
    Exhaust: 9.60mm
  • Rocker Ratio:
    Intake: 1.00
    Exhaust: 1.00
  • Net Valve Lift:
    Intake: 9.35mm
    Exhaust: 9.35mm
  • Advertise Duration @ 0.10mm:
    Intake: 260
    Exhaust: 260
  • Duration @ 1.00mm Valve Lift:
    Intake: 222
    Exhaust: 222
  • Timing @ 1.00mm Valve lift:
    INVO: 4 ATDC
    EVO: 52 BBDC
    IVC: 34 ABDC
    EVC: 8 TDC
  • Suggested Centre Lines:
    Intake: VARI
    Exhaust: 116
  • Valve Lift @ TDC
    Intake: 0.68mm
    Exhaust: 0.24
