MAHLE Power Pack Piston and Ring Kit 4.155 bore for Chevy LSX

**Image is a representation of this item. Actual item may vary.

Mahle Motorsports offers GM LSX Combo PowerPak piston and ring kits, designed for high-output, naturally aspirated, power-adder applications. These Combo PowerPak kits offer the best of strength in an all-forged aluminum alloy piston to allow for increased detonation resistance, and a combination valve pocket design that will cover LS1, LS3 and LS7 cylinder heads.

Features and benefits of these LSX Combo kits include:

* PowerPak pistons are all dual-coated with Phosphate coating to provide the piston's characteristic gray appearance (dry lubricant provides a lubricant film protection in the pin bores and ring grooves)
* Each slipper skirt is treated with Grafal; Mahle's proprietary coating to reduce wear, drag, scuffing, friction, and piston noise
* If the valve pocket layout is unknown when assembling the short block, these pistons will accommodate an LS1-style cathedral port, LS3-style rectangle port, and also LS7-style cylinder heads
* With listings for flat tops, dishes, and domes, these Combo PowerPak piston kits will not lock you into a single configuration, allowing for changes that can be made, as needed
* Compression ratios are available from 10:1 and cruise all the way up to 14:1 with bore options ranging from 4.000 in. to 4.185 in.

• Brand: Mahle
• Manufacturer Part Number: 930229755
• Bore Diameter: 4.155" / 105.537mm
• Compression Height: 1.110
• Piston Head Type: Dome, with two valve reliefs
• Piston Volume: -5.60cc
• Stroke: 4.000"
• Rod Length: 6.125"
• Piston Material: Forged Aluminum
• Wrist Pin Style: Press-fit or floating
• Wrist Pin Retainers Included: Yes
• Wrist Pin Included: Yes
• Pin Diameter: 0.927"
• Piston Ring Thickness: 1.00mm x 1.00mm x 2.00mm
• File Fit: Yes
• Gapless: No
• Top Ring Material: Ductile Iron
• Top Ring Facing Material: Plasma-moly
• Second Ring Material: Cast Iron
• Second Ring Facing Material: Cast Iron
• Oil Ring Material: Stainless Steel
• Oil Ring Tension: Standard
